Oracle 12c SE to 19c SE2 CDB Migration: A Field-Tested Runbook with Ansible Automation

Oracle ACE Program | May 2026 | Non-CDB to CDB | Data Pump Full Export/Import | APEX 24.1 | ORDS

Overview

This runbook documents a live migration of an Oracle 12c Standard Edition non-CDB database to Oracle 19c Standard Edition 2 as a Pluggable Database (PDB) within a new CDB. It covers planning, Ansible automation, Data Pump export/import, APEX upgrade, ORDS/DAD reconfiguration, and the real-world issues encountered and resolved during execution.

The migration was fully automated using Ansible playbooks developed specifically for this engagement. The approach is repeatable and has been generalized for use across multiple client environments.

Environment

Storage Planning

Storage gaps must be identified before cutover. Underestimating datafile growth is a common failure point in CDB migrations.

Storage Gap Analysis: Before go-live, calculate: DB size + 25% growth headroom for /d1; DB size × 2 for RMAN image copy backups on /b0. Use lvextend to expand volumes as needed. Storage gaps discovered too late are the #1 cause of failed cutovers.

Oracle 19c Software Installation

Oracle 19c was installed with a read-only Oracle home (orabasehome pattern). The following patches were applied before CDB creation:

The CDB was created via DBCA with the following key parameters:

• max_pdbs=3

• AL32UTF8 character set

• Listener ports: 1521 (default) and 1526 (application)

• FRA at /b0/fast_recovery_area, sized to 1160 GB

• systemd service oracle-database.service enabled for auto-start

• RMAN image copy backup scheduled daily at 20:00

Ansible Playbook Architecture

The migration was fully automated using a multi-role Ansible playbook. The playbook is idempotent and tagged by phase, allowing individual stages to be re-run independently.

Playbook Structure

site.yml                          # Master orchestration (7 phases, tagged)
inventory/hosts.ini               # source and target hosts
inventory/group_vars/all.yml      # Shared variables
inventory/group_vars/all/vault.yml # Encrypted passwords (ansible-vault)
roles/
  precheck_source/               # Source DB validation
  precheck_target/               # Target server validation
  export/                        # Data Pump export on source
  transfer/                      # NFS or rsync transfer
  create_pdb/                    # PDB creation and tablespace setup
  import_data/                   # Data Pump import phases
  postcheck/                     # Validation and recompile
playbook/create_and_import_pdb.yml # Main import playbook

Key Playbook Variables

pdb: MYAPPDB
pdb_number: 1
source_host: <source-db-server>
dump_dir: /t00/datapump/migration
db_port: 1526
apex_cdn: https://static.oracle.com/cdn/apex/24.1.6/
initiate_backup_on_complete: true

Execution Command

ansible-playbook playbook/create_and_import_pdb.yml \
  --extra-vars 'pdb=MYAPPDB pdb_number=1 \
    pdbadmin_pwd=<password> apex_pwd=<password> \
    source_host=<source-db-server> \
    initiate_backup_on_complete=true' \
  --diff

Data Pump Import Phases

The import was broken into discrete phases to allow targeted re-runs and to sequence dependent objects correctly. Each phase writes its own log file, and the playbook checks for log existence to implement idempotency.

Why Two User Import Passes? The first pass imports all schema objects. Many grants and cross-schema references fail because the target schema does not yet exist when the grant is processed. The second pass resolves these by re-running after all schemas are present. This is the recommended pattern for complex multi-schema databases.

Tablespace Creation

All tablespaces were pre-created before import using a SQL script generated from the source database.

The 32767M Datafile Limit

Oracle datafiles cannot exceed 32767 MB in smallfile tablespaces. Three tablespaces on the source had MAXSIZE values exceeding this limit and required adjustment:

Multi-Datafile Tablespace — Shell Heredoc Issue

The multi-datafile CREATE TABLESPACE syntax fails when passed through a shell heredoc because SQL*Plus interprets the continuation lines incorrectly (ORA-02197: file list already specified). The fix is to use CREATE followed by ALTER TABLESPACE ADD DATAFILE statements:

-- WRONG: fails through shell heredoc
CREATE TABLESPACE LOB_DATA01
  DATAFILE SIZE 1M AUTOEXTEND ON NEXT 128M MAXSIZE 32767M
  DATAFILE SIZE 1M AUTOEXTEND ON NEXT 128M MAXSIZE 32767M;  -- ORA-02197

-- CORRECT: CREATE + ALTER pattern
CREATE TABLESPACE LOB_DATA01
  DATAFILE SIZE 1M AUTOEXTEND ON NEXT 128M MAXSIZE 32767M;

ALTER TABLESPACE LOB_DATA01
  ADD DATAFILE SIZE 1M AUTOEXTEND ON NEXT 128M MAXSIZE 32767M;
-- Repeat ALTER for each additional datafile needed

Issues Encountered and Resolutions

The following issues were encountered during the live migration. Each is documented with root cause and resolution for future reference.

Issue 1: ORA-12154 — TNS Could Not Resolve Service Name

Root cause: The target server had no tnsnames.ora entry for the source database. The impdp process on the target could not resolve the source PDB service name.

Resolution: Add a tnsnames.ora entry on the target pointing to the source listener:

MYAPPDB =
  (DESCRIPTION =
    (ADDRESS = (PROTOCOL = TCP)(HOST = <source-db-server>)(PORT = 1521))
    (CONNECT_DATA = (SERVICE_NAME = myappdb.<your-domain>)))

Issue 2: Stale impdp Log Files After PDB Recreation

Root cause: The playbook uses log file existence to determine whether a phase has already run (idempotency). After the PDB was dropped and recreated, stale log files from previous runs caused the playbook to skip the user import phases entirely. Schemas were never imported, causing all subsequent steps to fail with ORA-01918: user does not exist.

Resolution: Before re-running the playbook after any PDB recreation, delete all impdp log files:

rm /t00/<source-db-server>/<pdb-name>/export/impdp_users_1.log
rm /t00/<source-db-server>/<pdb-name>/export/impdp_users_2.log
rm /t00/<source-db-server>/<pdb-name>/export/impdp_tables.log
rm /t00/<source-db-server>/<pdb-name>/export/impdp_roles.log
rm /t00/<source-db-server>/<pdb-name>/export/impdp_apex.log

Key Lesson: Log-file-based idempotency is fragile after PDB recreation. A more robust approach is to query the data dictionary to verify whether objects actually exist before skipping a phase, rather than relying solely on log file presence.

Issue 3: APEX PRINT_SVR_TIMEOUT Removed in 24.1

Root cause: The APEX instance settings script included PRINT_SVR_TIMEOUT, which was removed in APEX 24.1. The set_parameter call fails with ORA-20987: Instance parameter not found.

Resolution: Remove PRINT_SVR_TIMEOUT from the APEX instance settings script. The parameter no longer exists in APEX 24.1.

Issue 4: ORA-02030 — Cannot Grant on v$pdbs Directly

A grant on v$pdbs fails from within a PDB context. Use the underlying fixed view instead:

-- WRONG
GRANT SELECT ON v$pdbs TO app_owner;  -- ORA-02030

-- CORRECT
GRANT SELECT ON sys.v_$pdbs TO app_owner;

Issue 5: PDB in Restricted Mode After Import

Root cause: Data Pump sets the PDB to restricted mode during certain full import operations. ORDS reports ORA-01035: ORACLE only available to users with RESTRICTED SESSION privilege.

Diagnosis:

-- Check from CDB root
SELECT con_id, name, open_mode, restricted FROM v$pdbs;
-- RESTRICTED = YES confirms the issue

Resolution:

ALTER SESSION SET CONTAINER = MYAPPDB;
ALTER SYSTEM DISABLE RESTRICTED SESSION;

-- Verify
SELECT con_id, name, open_mode, restricted FROM v$pdbs WHERE name = 'MYAPPDB';
-- Should show RESTRICTED = NO

If ALTER SYSTEM does not clear it, close and reopen the PDB:

ALTER PLUGGABLE DATABASE MYAPPDB CLOSE IMMEDIATE;
ALTER PLUGGABLE DATABASE MYAPPDB OPEN;
ALTER PLUGGABLE DATABASE MYAPPDB SAVE STATE;

Add to Playbook: Add an explicit ALTER SYSTEM DISABLE RESTRICTED SESSION step immediately after the import completes, before any ORDS or application connectivity checks. This issue will occur on every import run.

Issue 6: ORDS Connection Pool User Locked

Root cause: The ORDS low-privilege pool user account was locked during import due to failed connection attempts against the restricted PDB. ORDS reports ORA-28000: The account is locked.

Diagnosis:

SELECT username, account_status, lock_date
FROM dba_users
WHERE account_status != 'OPEN'
ORDER BY lock_date DESC;

Resolution:

ALTER SESSION SET CONTAINER = MYAPPDB;
ALTER USER <ords-pool-user> ACCOUNT UNLOCK;

-- If also expired:
ALTER USER <ords-pool-user> IDENTIFIED BY <password> ACCOUNT UNLOCK;

After unlocking, restart ORDS if the pool does not reconnect automatically:

sudo systemctl restart ords

Issue 7: ORA-65040 — Cannot Create Public Synonym from PDB

Certain public synonyms (such as PLAN_TABLE) cannot be created from within a PDB context. The error is expected and harmless — PLAN_TABLE is a system-provided synonym at the CDB level.

Resolution: Remove the affected synonym from the create_synonyms.sql script. No action required.

Issue 8: ORA-00995 — Invalid Synonym Identifier

A public synonym with an internally-generated name starting with a special character (e.g. /1a9c9a96_...) cannot be created as a synonym — the name is not a valid Oracle identifier.

Resolution: Remove the affected synonym from the script. The underlying object is an internal APEX artifact that is recreated correctly by the APEX installation itself.

APEX Migration

Approach: Fresh Install

Rather than migrating the existing APEX installation via Data Pump, a fresh APEX 24.1 installation was performed in the target PDB. APEX workspaces and applications were then imported separately using a dedicated Data Pump dump file created from the source.

This approach avoids compatibility issues between APEX versions and ensures the target has a clean, fully-patched APEX schema before application data is loaded.

Installation Sequence

1. Install APEX 24.1 base release (apexins.sql) in silent mode

2. Apply patch 36695709 (APEX 24.1.6)

3. Configure CDN image prefix: https://static.oracle.com/cdn/apex/24.1.6/

4. Import APEX workspaces and applications from source dump

5. Configure instance-level parameters to match source

Key APEX Instance Settings That Differ From Defaults

ORDS and DAD Configuration

Connection Pool

ORDS uses named connection pools per PDB. The pool name follows the pattern |<pdb_name>|lo| for the low-privilege user and |<pdb_name>|hi| for the privileged user.

# ORDS pool configuration
db.hostname=<target-db-server>
db.port=1526
db.servicename=myappdb.<your-domain>
db.username=<ords-public-user>

DAD Migration Checklist

• Update db_hostname to target server FQDN

• Update db_port to target listener port

• Re-obfuscate passwords against the new OHS home (obfuscated passwords are OHS-installation-specific)

• Verify request_validation_function references for any DADs that use custom validation

• Test each DAD endpoint after ORDS restart

ORDS Troubleshooting Reference

Post-Import Checklist

Immediate — Before Declaring Migration Complete

1. Disable restricted session: ALTER SYSTEM DISABLE RESTRICTED SESSION

2. Unlock application service accounts (ORDS pool users, selfservice accounts)

3. Run utlrp.sql to recompile all invalid objects

4. Check invalid object count: SELECT count(*) FROM dba_objects WHERE status = 'INVALID'

5. Run targeted imports for any tables that failed due to missing schemas

6. Re-enable constraints and triggers

7. Verify table row counts against source for key tables

8. Test APEX login and application functionality

9. Test each ORDS/DAD endpoint

10. Review alert log for ORA- errors

Before Production Cutover

1. Change SYS, SYSTEM, and pdbadmin passwords from migration defaults

2. Run lvextend on /d1 if storage headroom is insufficient (target: DB size + 25%)

3. Run lvextend on /b0 for RMAN image copy backups (target: DB size × 2)

4. Verify RMAN backup completes successfully

5. Verify oracle-database.service starts correctly after simulated reboot

6. Configure monitoring and alerting for the new PDB

7. Update DNS/load balancer entries for application endpoints

8. Document final connection strings for application teams

Playbook Improvements for Future Runs

• Add ALTER SYSTEM DISABLE RESTRICTED SESSION after import completes

• Add automatic unlock of application service accounts post-import

• Replace log-file idempotency with data dictionary checks

• Remove PRINT_SVR_TIMEOUT from APEX instance settings script (removed in 24.1)

• Use CREATE + ALTER ADD DATAFILE pattern for all large tablespaces

• Add pre-flight storage gap check that fails early if headroom is insufficient

Security Considerations

• All passwords are stored in Ansible vault (ansible-vault encrypt_string). Never store plaintext passwords in playbook variables or inventory files.

• The pdbadmin password used during migration must be changed before production use.

• SYS and SYSTEM passwords must be changed before production use.

• ORDS pool user passwords should be rotated after migration and stored in the ORDS wallet, not in plaintext configuration files.

• Obfuscated OHS passwords (@B...) must be re-obfuscated against the new OHS home after migration. Obfuscation is tied to the OHS installation.

• Review DBA_SYS_PRIVS for any overly-broad grants carried over from the source.

Key Takeaways

What Worked Well

• Breaking the import into discrete, logged phases made it easy to re-run individual steps without starting over

• Installing APEX fresh and importing workspaces separately avoided version compatibility issues

• Pre-creating all tablespaces before import prevented mid-import failures on large LOB tablespaces

• The Ansible playbook reduced a complex multi-hour manual process to a single command

What to Watch Out For

• Stale log files after PDB recreation silently skip import phases — always clean logs before re-running

• The PDB will be in restricted mode after a Data Pump full import — always add DISABLE RESTRICTED SESSION to your post-import steps

• Multi-datafile CREATE TABLESPACE fails through shell heredocs — use CREATE + ALTER ADD DATAFILE

• APEX instance parameters change between versions — always compare source vs target after APEX install

• Storage gaps discovered at cutover time cause emergency outages — calculate and provision storage during planning, not during execution

The Non-CDB to CDB Shift

Moving from a non-CDB to a CDB architecture changes several operational assumptions:

• Public synonyms cannot be created from within a PDB for CDB-level objects (ORA-65040)

• v\( views must be granted as sys.v_\)<view> from within a PDB

• Each PDB has its own DEFAULT profile — profile limits from the source must be re-applied explicitly

• PDB restricted mode is separate from CDB restricted mode — check v\(pdbs.restricted, not just v\)instance.logins

• RMAN backup strategies need to account for CDB-level vs PDB-level backup scope

Platform: Oracle 19c SE2 (19.24.0.0.0) | APEX 24.1.6 | Ansible 2.x | Oracle Linux 9

All client-specific identifiers have been generalized. This runbook is based on a live migration engagement conducted in May 2026.
